Power Mover |
|
Specifications |
|
|
|
|
|
| Overall Length |
|
|
53" |
|
|
| Overall Width |
|
|
38" |
|
|
| Overall Height |
|
|
38" |
|
|
| Weight (including batteries) |
|
|
550 lbs. |
|
|
| Tongue Weight Load (front lift) |
|
|
1,000 lbs. |
|
|
| Tongue Weight Load (center lift) |
|
|
NA |
|
|
| Standard Caster Wheel Size (rear) |
|
|
6" |
|
|
| Steering Wheel Size (rear) |
|
|
NA |
|
|
| Tire Size (front) |
|
|
18x9.5x8" |
|
|
| Drive Type Axle |
|
|
Stub Axle |
|
|
| Batteries (standard) |
|
|
(2)SRM 31 |
|
|
|
Features & Options |
| Single Speed Control |
|
|
NA |
|
|
| Variable Speed Control |
|
|
S |
|
|
| Built-In Battery Charger(s) |
|
|
S (1) |
|
|
| Battery Level Indicator |
|
|
S |
|
|
| Hour Meter |
|
|
S |
|
|
| DC Motor 3/4 HP |
|
|
NA |
|
|
| DC Motor 2 HP Intermittent |
|
|
S |
|
|
| DC Motor 2 HP (continuous duty) |
|
|
O |
|
|
| Hydraulic Lift (front 7" travel) |
|
|
O |
|
|
| Electric Lift (12v DC 8" travel) |
|
|
O |
|
|
| Hydraulic Lift HD (16" travel) |
|
|
NA |
|
|
| Foam Filled Tires |
|
|
O |
|
|
| Non-Marking Tires (grey) |
|
|
O |
|
|
| Locking Type Hub |
|
|
NA |
|
|
| Electric Trailer Brake Connection |
|
|
O |
|
|
| All-Terrain Tire Package |
|
|
O |
|
|
| Weight Kit |
|
|
O |
|
|
| Auxiliary Hydraulic Quick Con. Kit |
|
|
O |
|
|
|
Speed/Torque Package |
| Max 1 mph & approx. 1500 ft. lbs |
|
|
O |
|
|
| Max 1.6 mph & approx. 1000 ft. lbs |
|
|
S |
|
|
| Max 2.7 mph & approx. 600 ft. lbs |
|
|
O |
|
|
| Max .53 mph & approx. 500 ft. lbs |
|
|
NA |
|
|
| Max .73 mph & approx. 500 ft. lbs |
|
|
NA |
|
|
|
Attachments |
| Hitch Ball |
|
|
S |
|
|
| Pintle Hook |
|
|
O |
|
|
| J-Hook |
|
|
O |
|
|
| Pin |
|
|
O |
|
|
| Ring |
|
|
O |
|
|
| Custom Made |
|
|
O |
|
|
| 5th Wheel Hitch |
|
|
NA |
|
|
