Main Technical Parameter



Model

12PSB 7.5KW

12PSB 11KW

12PSB 15KW

12PSB 18.5KW

1.

Rotation speed range of main shaft(rpm)

0-4000

0-3000

0-3000

0-3000

2.

Motor output power(KW)

7.5

11

15

18.5

3.

Pump output power(KW)

0.75

0.75

0.75

1.1

4.

Height from center line of main shaft to work table(mm)

125

125

125

125

5.

Rotation direction of main shaft

Positive, negative

Positive, negative

Positive, negative

Positive, negative

6.

Testable cylinders of injection pump

12

12

12

12

7.

Standard model of fuel injector

.

8.

Oil injection count range

0-1000

0-1000

0-1000

0-1000

9.

Capacity of oil tank(L)

>50

>50

>50

>50

10.

Pressure of fuel system

High

0-4

0-4

0-4

0-4

Low

0-0.4

0-0.4

0-0.4

0-0.4

11.

Supply oil capacity(L/min)

>10

>10

>10

>10

12.

Temperature of fuel()

402

402

402

402

13.

Precise of fuel filter(μ)

5

5

5

5

14.

Capacity of measuring cup(ml)

45/150

45/150

45/150

45/150

15.

Pressure of air way (Mpa)

Positive

0-0.3

0-0.3

0-0.3

0-0.3

Negative

-0.05-0

-0.05-0

-0.05-0

-0.05-0

16.

DC voltage(V)

12/24

12/24

12/24

12/24

17.

Package dimension(m)(LWH)

2.21.151.8

2.21.151.8

2.21.151.8

2.41.21.8

18.

Weight(Kg)

900

900

1050

1050





             Fuel pump test bench main function

1. Measurement of the delivery at various rotation speed.

2. Checking of beginning and interval angle of the pump.

3. Checking of the mechanical speed regulators.

4. Checking of the electromagnetic valve of distribution pump.

5. Checking of the pneumatic speed regulators.

6. Checking of the pressure compensators (LDA).

7. Measurement of the reflux delivery of distribution pump.

8. The test and adjustment of distribution pump.

9. Measurement of interior pressure of distribution pump.

10. Checking of the vacuum capacity regulators.

11. Advance angle measurement.

12. Checking of the sealing of injection pump.

13. Self-suction joint.

14. Printer (optional).

15. Data-base (optional).

16. Measure rack bar travel (optional).





1



fuel injection pump test bench

12PSB-

1

2



plastic overalls



2m1.8m1m

1

3



standard injector



ISO7440A14-172

12

4



high pressure tube

M141.5/M12X1.5840

6

5



Diameter changing joint



M141.5/M121.5

12

6



graduates

45ml, 150ml

each 12

7



fuel supply pipe



M201.5120Omm(rubber pipe)

       1

8



oil return pipe



M2O1.5100Omm(PVC pipe)

       1

9



hollow screw



Ml41.5

M121.5

each 2



M121.25

M181.5

10



Pulling bar for scale







       1

11

Location block

III(A〉、Ⅲ(B)、ZPP7P7100

each 2

12



Multi-purpose angle iron assembly



       1

13



clamp bow







       1

14



shaft coupling



III、Ⅲ、Ⅳ、7555

each 1

15



rubber anti-vibration cushion



4

16



in hexagonal head wrench



S=5

S=10

each l

17

Copper gasket



12、¢14、¢18

each 4

18



direct current power wires



1

19



Speed regulation potentiometer



0616X

2KΩ

1

20



T nut

M12

3

21



                    bolt



M12x80

2

22



                   bolt



M12x50

4

23



Clip for small graduates



4

24



         Circuit breaker



C65N

2

25



VE attachment



1

26



Air pipe assembly

6 air pipe, 8 direct through, 10direct through, 12 direct through

each l

27



VE rubber tube



14-M161.51200mm

1

28



Diameter changing joint

M141.5/M181.5

6

29



swivel joint

18.5、¢14.5、¢12.5

each 2

30



working lamp



1

31



Sensor support







1

32



Advance angle shaft coupling







1

33



flange plate

6112

l

Technical document

1



product instruction booklet







1

2



packing list







1

3



product certificate







1















Packing  List
